Finished! Well, almost!

After great labour, I created a "chrome" polished bayonette. I built a scabbard out of brass, and plated it. I cast and finished pewter handles for it. They are not plated yet, but I was doing a test fit, and figured I would take a picture. Not too shabby! When the pewter comes back from the plater, it will be as shiney as the rest of the unit! I am even getting the screws which join the two halves together plated! This might get interesting if the nickel messes up the threads on the screws! But I'll cross that bridge when I come to it.

As usual, it is hard to photograph a mirror! You can see the reflections of the yellow curtains in the scabbard! Yup...its shiny all right!

Click on the pictures to enlarge...

Cleaning up the castings

These two pics are of the same items...the blue painted one eventually got filed into the one in the middle in the top picture.

Now the real work starts! I sit down at the bench with my little triangular jeweler's files, and clean up the whole casting. It needed every single point to be re-freshed, and all the flat surfaces to be cleaned up with files, sandpaper, and eventually, a high speed buffer. The above picture shows the original black plastic handle, a handle which is well into the process of filing it clean, and the one on the right is what it looked like when it came out of the mould. I spray on blue ink so that I can remember which parts I have done...it all reflects light and is hard to focus on. I was well aware that one sloppy stroke of the file could ruin hours of work!


I understand the proper name for such a casting is called a "finding". That is...something which is actually produced in a "foundry".

I got complacent. I did one perfectly in what....14 hours or so, and the next one went a little faster, only 12 hours. I figured I knew what I was doing, so I cut off the sprues with the hacksaw, and carved the saw into the casting, ruining 12 hours of work in two saw cuts! Doooh!
The third one came along quite well, but because I had already used the two best findings for the job, it took a lot longer, about 18 hours, to finally clean up the "checkering" on the sides, cut the sprues and drill them out, and generally decide I was satisfied with the job.

The second picture up there shows the original, a casting, and my finished filed handle half. This pic was actually taken before I had done the final buffing, and I note that the usual problems of photographing mirrors is coming into play! The bottom edge looks rough, but actually, what it doing is reflecting the rough surface of the cloth it is sitting on!

Bayonette finishing

The first part of making a handle out of metal is to make the mould. I used a two part material called ATV325. It mixes like epoxy, and forms a rubber like compound which surprisingly enough, is quite resistant to heat. Useful since I would be pouring molten pewter into it! I used the existing handle halves to form the mould. Those are the black handle halves you see in the above pictures. Unfortunately, I didn't know how "rubbery" it really was, and its jello like consistency caused some problems due to distorted moulds. Well, that is the learning process I guess! I tried a couple of ways to pour....through the side, through the top. The top picture is of the mould wrapped up with a leather thong ready to use, with some of the cute little handle halves I made. I eventually made about 12 of them, of which 3 were good enough castings to actually use, and another six which simply got tossed back into the frying pan to melt.

There are things about pewter I never realized. For one thing, there is the "fizz" which comes out of it when it is poured. Like bubbles in soda pop, they seem to come from nowhere, and the bubbles come up the "sprues", making the sprues really porous. Ruins the surface of the casting as well...you can see how rough it makes the casting in some of the pictures above.

The end result of a couple of days trial and error (its not like I ever did anything like this before!) I got a nice bunch of nice hard shiney pewter handles, covered in pits from bubbles, oxodized from overheating, several little blisters on my hands, and a warm feeling. No wait, that was from the hot plate I forgot to turn off!

Click on images to enlarge.

Big project...Bayonettes!

The challenge was to take the standard issue bayonette and chrome plate it. The purpose of a chrome bayonette is to fancy up the funeral party for the re-patriation ceremony for our fallen soldiers. This seemed like a job I could respect! The ones they had been using up until now were from the old Belgian "Fabrique National Canadian Model One", the famous FNC1 which had been in use for most of the last half of the 20th century...but enough people were wondering why the funeral party wasn't using the modern bayonette...after all, they were using the modern sidearm! Well, the answer is simple. Plastic scabbard. Plastic handles. Impossible to plate!
Or is it? There seem to be a LOT of chrome plated plastic out there...my motorcycle seems covered with it. Well, it seems there are plastics which can be plated and plastics which cannot be plated. Nobody was sure if the C7 bayonette plastic bits were actually of a type which could be plated, and nobody cared for an order under a thousand units! So, I jumped up and said...hell yes! I can make a scabbard out of brass which will be impossible to distinguish from the plastic one. No really! I can do that! And I can cast the handles out of pewter, and plate those too!

Imagine my surprise when they took me up on it. So, I made them. I figure I am making less than a buck an hour on this job, but hey....its worth the effort! For these guys, I wish I could do more!

First step was get the brass. Cut it out, and roll the edges up and around a metal blank. Then roll the half scabbard in the english wheel in order to flatten it. Then make the button for the "frog"...a little cylinder of leather with a slot in it which holds the bayonette onto the uniform belt.

The tricky job was to solder the brass halves together. I use a solder which is about 30% silver, and 60% tin, with some other metals mixed in to lower the melting point. The picture shows the bayonette after I had polished and nickeled it (on the right), and the progression from left to right of the soldering.

This took me about 26 hours. Per scabbard. Counting the half dozen that failed and ended up on the scap heap!

Tomorrow, I'll take pictures of the bayonette itself. All polished up...looks fantastic!
